•        A strong structure has been designed in brake assembly and design.
•        Noise level in brakes <70 Db
•        High braking torque is provided for motors of different sizes.
•        Cooled type brakes; It helps to expel the heat generated during braking, thus minimizing lining wear.
•        Electromagnetic winding is wrapped on coil mold prepared from heat resistant material and protected with epoxy. (coil insulation class H-180 °).
•        All mechanical parts are electrolyzed and protected against corrosion.
•        Brake lining discs are made of aluminum injection at low moments and antimagnetic stainless steel at large moments.
•        Asbestos-free linings with high friction coefficient are used in brakes.
•        Brake coil bodies are manufactured from GGG 42 ductile iron and hysteresis losses are minimized.
•        Brakes are designed to be used in all kinds of motors by changing the interconnection flange.
•        Brakes can work in any position.
•        All mechanical parts are processed on CNC benches.
•        All brakes are designed for microswich, proksyswich and encoder mounting.
•        Brakes are produced as 24 Vdc and 98 Vdc 198 Vdc as standard except special requests.
•        Brakes are produced in DF model between 5 Nm and 1600 Nm torques.
